Team Engines & Demons:
The SAE INDIA Collegiate Club of IIT Indore is a spirited and active society of students that indulge in educative and knowledge-sharing activities, workshops and competitions spreading a buzz in the campus. Engines & Demons is the 25 member team of automobile-fanatic students with a passion to compete and win!
Indian Institute of Technology Indore is one of the newest premier institute for engineering in the nation with an aspiration to earn national and international accolades starting with BAJA 2013.
Technical Specifications
Overall:
• Dimensions : (62 X 50 X 64)"
• Weight of vehicle : 350 kg (with driver)
• Ground clearance : 8"
• Track width : 54"
• Wheel base : 45"
Chassis:
• Construction : Tubular space frame (1in X 0.125in)
Square frame (1in X 1in)
• Material : AISI 1018
• Welding : TIG Welding
• Overall chassis weight : 65 kg
Suspension:
• Type : Double Wishbone Independent Suspension
• Wishbone material : IS 1239
• Designed Spring Travel : Front: 3.5in jounce, 0.8in rebound
Rear: 3.75in jounce, 0.92in rebound
Engine:
Briggs & Stratton 20S232 0036
Single Cylinder Four Stroke Air Cooled Engine
• Power : 10hp @3800rpm
• Max Torque : 19.6Nm @2800rpm
Transmission:
• Type: Rear wheel drive
• CVT : Polaris (3.83:1 to 0.76:1)
• Gearbox Ratio : 5:1
• Final Drive Type : Chain & Sprockets connected to the Rear Axle
Steering:
• Turning Radius : 2.7m
• Steering Ratio : 17:1
Brakes:
Type : Maruti 800 Disc Brakes on all wheels
